Vivitek D7 Series User Manual

DLP Projector – User’s Manual
– 6 –
ITEM LABEL DESCRIPTION SEE PAGE:
1.
IR transmitter Transmits signals to projector
2.
Status LED Lights when the remote control is used
3.
Laser Press to operate the on-screen pointer
4.
Up Up arrow when connected through USB to a PC
5.
Right Right arrow when connected through USB to a PC
6.
Down Down arrow when connected through USB to a PC
7.
Page Down Page down when connected through USB to a PC
8.
Up cursor
9.
Right cursor
10.
Down cursor
Navigates and changes settings in the OSD
17
11.
Volume +/- Adjusts volume
16
12.
Mute Mutes the built-in speaker
13.
Zoom+ Zoom in
14.
Zoom- Zoom out
15.
Freeze Freeze/unfreezes the on-screen picture
16.
Blank Makes the screen blank
17.
Source Detects the input device
18.
Auto Auto adjustment for phase, tracking, size, position
19.
Menu Opens the OSD
17
20.
Status
Opens the OSD Status menu (the menu only opens when an
input device is detected)
38
21.
Keystone top/bottom Corrects image-trapezoid (wider top/bottom) effect
15
22.
Left cursor Navigates and changes settings in the OSD
23.
Enter
Changes settings in the OSD
24.
Page Up Page up when connected through USB to a PC
25.
Left Left arrow when connected through USB to a PC
26.
Enter Enter key when connected through USB to a PC
17
27.
Power Turns the projector on or off
10
28.
Laser Use as on-screen pointer. DO NOT POINT IN EYES.
