Timing Mode Table
The projector can display several resolutions. The following table outlines the resolutions that can be
displayed by the projector.
SIGNAL RESOLUTION
H-SYNC
(KHZ)
V-SYNC
(HZ)
COMPOSITE
/ S-VIDEO
COMPONENT
RGB
(ANALOG)
DVI/
HDMI
TM
(DIGITAL)
NTSC — 15.734 60.0 O
—
－ －
PAL/SECAM — 15.625 50.0 O
—
－ －
720 x 400 37.9 85.0 — — O O
640 x 480 31.5 60.0 — — O O
640 x 480 37.9 72.8 — — O O
640 x 480 37.5 75.0 — — O O
640 x 480 43.3 85.0 — — O O
800 x 600 35.2 56.3 — — O O
800 x 600 37.9 60.3 — — O O
800 x 600 46.9 75.0 — — O O
800 x 600 48.1 72.2 — — O O
800 x 600 53.7 85.1 — — O O
1024 x 768 48.4 60.0 — — O O
1024 x 768 56.5 70.1 — — O O
1024 x 768 60.0 75.0 — — O O
1024 x 768 68.7 85.0 — — O O
1280 x 800 49.7 59.8 — — O O
1280 x 1024 64.0 60.0 — — O O
1280 x 1024 80.0 75.0 — — O O
1280 x 1024 91.1 85.0 — — O O
1400 x 1050 65.3 60.0 — — O O
VESA
1600 x 1200 75.0 60 — — O O
640 x 480 35.0 66.7 — — O O
832 x 624 49.7 74.5 — — O O
1024 x 768 60.2 74.9 — — O O
Apple
Macintosh
1152 x 870 68.7 75.1 — — O O
480i 15.734 60.0 — O — O
SDTV
576i 15.625 50.0 — O — O
576p 31.3 50.0 — O — O
EDTV
480p 31.5 60.0 — O — O
