Views of Projector Parts
D825MS/D825MX Front-right View
ITEM LABEL DESCRIPTION SEE PAGE:
1.
IR receiver Receive IR signal from remote control
6
2.
Height-adjuster button Push to release height adjuster
3.
Height adjuster Adjusts level of projector
15
4.
Lens cap
Protect lens when not in use
5.
Lens Projection Lens
6.
Focus ring Focuses the projected image
7.
Zoom ring
(D825MX only)
Enlarges the projected image
16
8.
Function keys
See Top view—On-screen Display (OSD) buttons and
LEDs.
3
Important:
Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp
cool. Do not obstruct any of the ventilation openings.
