Vivo DESK-E355B - Page 12

12
A-STEP 7: Secure Frame & Desktop
Q (x1)
Control Panel
Secure to desktop with M5x16mm Screws (S-C) and a Phillips screwdriver, using the screw
locations shown below. Connect Control Panel (Q) to desktop using M5x16mm Screws (S-C)
and a Phillips screwdriver.
Q
S-C
S-C
S-C (x25)
M5x16mm Screw
