18
B-STEP 7: Secure Frame & Desktop
Q (x1)
Control Panel
Secure to desktop with M5x16mm Screws (S-C) and a drill, using the screw locations shown
below. Connect Control Panel (Q) to desktop using M5x16mm Screws (S-C) and a drill.
S-C (x25)
M5x16mm Screw
S-C
S-C
Q
