9
A-STEP 4: Install Anti-Vibration Pads
ASSEMBLY OPTION A | Le Side Extension
Aix Anti-Vibration Pads (V) to the desk frame and Connector Bracket (N).
V (x19)
Anti-Vibration Pads
N (x1)
Connector Bracket
V
N
