EN - 4
First, follow the instructions below to remove the dome cover. Flip the black retention tabs
in the counter-clockwise direction to release the dome cover (clockwise if you look from the
bottom up.)
Hardware Installation
3
Physical Description
2
Dome Cover
Lens
Reset Button
General I/O Terminal Block
Status LED
MicroSD/SDHC
Card Slot
Black Cover
Ethernet 10/100 RJ45
Plug
Power Cord Socket
Record the MAC address before
installing the camera.
Network Camera
Model No: FD8131
Made in Taiwan
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Pat. 6,930,709
RoHS
V I
MAC:0002D107258A
Ground wire
To Next Page
