The sophisticated 3-axis mechanism design offers very exible, easy hardware installation
for either ceiling or wall mount.
3-axis Mechanism Design
Pan 350°
Rotate 340°
Tilt Adjustment Screw
DO NOT over rotate the lens.
Doing so will damage the
camera lens module.
FD8133V: Tilt 85°
FD8134V: Tilt 70°
