58
the certificate information.
commonname string[64] www.vivotek.c
om
6/6 Common name in the
certificate information.
validdays 0 ~ 3650 3650 6/6 Valid period for the
certification.
7.29 Storage management setting
Currently it’s for local storage (SD, CF card)
Group: disk_i<0~(n-1)> n is the total number of storage devices.
PARAMETER VALUE Default SECURITY
(get/set)
DESCRIPTION
cyclic_enabled <boolean> 0 6/6 Enable cyclic storage method.
autocleanup_enabled <boolean> 0 6/6 Enable automatic clean up method.
Expired and not locked media files
will be deleted.
autocleanup_maxage <positive
integer>
7 6/6 To specify the expired days for
automatic clean up.
7.30 Region of interest
Group: roi_c<0~(n-1)> for n channel product, and m is the number of streams which support ROI.
PARAMETER VALUE Default SECURITY
(get/set)
DESCRIPTION
s<0~(m-1)>_home <coordinate> 0,0
320,200
0,0
1/6 ROI left-top corner coordinate.
s<0~(m-1)>_size <window size> 1280x800
640x400
1280x800
1/6 ROI width and height. The width
value must be multiples of 16 and
the height value must be
multiples of 8
7.31 ePTZ setting
Group: eptz_c<0~(n-1)> for n channel product. (capability.eptz > 0)
PARAMETER VALUE Default SECURITY
(get/set)
DESCRIPTION
osdzoom <boolean> 1 1/4 Indicates multiple of zoom in is
“on-screen display” or not
