weekday 0~127 127 6/6 Indicate which weekday is scheduled.
One bit represents one weekday.
bit0 (LSB) = Saturday
bit1 = Friday
bit2 = Thursday
bit3 = Wednesday
bit4 = Tuesday
bit5 = Monday
bit6 = Sunday
For example, to detect events on Friday
and Sunday, set weekday as 66.
begintime hh:mm 00:00 6/6 Begin time of the weekly schedule.
endtime hh:mm 24:00 6/6 End time of the weekly schedule.
(00:00 ~ 24:00 sets schedule as always
on)
lowlightcondition
<product dependent>
0, 1 1 6/6 Switch on white light LED in low light
condition
0 => Do action at all times
1 => Do action in low-light conditions
action_do_i<0~(ndo-1)
>_enable
0, 1 0 6/6 Enable or disable trigger digital output.
action_do_i<0~(ndo-1)
>_duration
1~999 1 6/6 Duration of the digital output trigger in
seconds.
action_cf_enable <Boolean> 0 6/6 Enable or disable sending media to SD
card.
action_cf_folder string[128] <blank> 6/6 Path to store media.
action_cf_media NULL, 0~4,101 <blank> 6/6 Index of the attached media.
action_cf_datefolder <boolean> 1 6/6 Enable this to create folders by date,
time, and hour automatically.
action_cf_backup <Boolean> 0 6/6 Enable or disable the function that send
media to SD card for backup if network is
disconnected.
action_server_i<0~4>_e
nable
0, 1 0 6/6 Enable or disable this server action.
action_server_i<0~4>_
media
NULL, 0~4,101 <blank> 6/6 Index of the attached media.
101 means “Recording Notify”
action_server_i<0~4>_
datefolder
<boolean> 0 6/6 Enable this to create folders by date,
time, and hour automatically.
