Vivotek FD8155H User Manual

VIVOTEK
10 - User's Manual
1. Attach the alignment sticker to the ceilling/wall.
2. Through the two circles on the sticker, drill two pilot holes into the ceilling/wall.
3. The Network Camera can be mounted with the cable routed through the ceiling/wall or
from the side. If you want to feed the cable through the ceiling/wall, drill a cable hole.
4. Hammer the supplied plastic anchors into the holes.
5. Align the holes on the camera with the plastic anchors on the ceilling/wall, secure the
camera with the included screws.
Wall Mount
Ceiling Mount

Vivotek FD8155H Specifications

General

Brand	Vivotek
Model	FD8155H
Category	Security Camera
Language	English
