VIVOTEK
User's Manual - 219
Technical Specications
6F, No.192, Lien-Cheng Rd., Chung-Ho,
New Taipei City, 235, Taiwan, R.O.C.
T: +886-2-82455282 F: +886-2-82455532
E: sales@vivotek.com
VIVOTEK INC.
2050 Ringwood Avenue,
San Jose, CA 95131
T: 408-773-8686 F: 408-773-8298
E: salesusa@vivotek.com
VIVOTEK USA
Randstad 22-133, 1316BW Almere,
The Netherlands
T: +31(0)36 -5298- 434
E: saleseurope@vivotek.com
Ver. 5
Distributed by:
All specifications are subject to change without notice. Copyright © VIVOTEK INC. All rights reserved.
VIVOTEK Europe
Model FD 8155H
System Information
CPU Multimedia SoC (System-on-Chip)
Flash 256MB
RAM 384MB
Camera Features
Image Sensor 1/3" Progressive CMOS
Maximum Resolution 1280x1024 (1.3MP)
Lens Type Vari-focal, Remote Focus
Focal Length f = 3 ~ 10 mm
Aperture F1.3 ~ F2.5
Auto-iris P-iris/DC-iris (Reserved)
Field of View
30° ~ 95° (Horizontal)
24° ~ 75° (Vertical)
39° ~ 123° (Diagonal)
Shutter Time 1/5 sec. to 1/10000 sec.
WDR Technology WDR Pro II
Day/Night
Removable IR-cut filter for day & night function
Smart IR Technology to avoid overexposure (WDR on)
Minimum Illumination
0.05 Lux @ F1.3 (Color)
0.001 Lux @ F1.3 (B/W)
Pan/tilt/zoom Functionalities
ePTZ:
48x digital zoom (4x on IE plug-in, 12x built in)
IR Illuminators
Built-in IR illuminators, effective up to 30 meters
IR LED*4, with Smart IR Technology
On-board Storage MicroSD/SDHC/SDXC card slot
Video
Compression H.264, MJPEG
Maximum Frame Rate
30 fps @ 1280x1024
60 fps @ 1280x1024 (One-stream mode only)
In both compression modes
Maximum Streams 2 simultaneous streams
S/N Ratio 64dB
Dynamic Range Up to 140dB
Video Streaming Adjustable resolution, quality and bitrate
Image Settings
Time stamp, text overlay, flip & mirror
Configurable brightness, contrast, saturation, sharpness, white
balance, exposure control, gain, backlight compensation,
privacy masks, scheduled profile settings, 3D noise reduction,
seamless recording
Audio
Audio Capability Two-way audio (full duplex)
Compression AAC, G.711, G.726
Interface
External microphone input
Audio output
Network
Users Live viewing for up to 10 clients
Protocols
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP,
SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP,
802.1X, UDP, ICMP
Interface 10Base-T/100 BaseTX Ethernet (RJ-45)
Technical Specifications
Compatible Accessories
ONVIF Supported, specification available at www.onvif.org
Intelligent Video
Video Motion Detection Triple-window video motion detection
Alarm and Event
Alarm Triggers
Video motion detection, manual trigger, digital input,
periodical trigger, system boot, recording notification, camera
tampering detection
Alarm Events
Event notification using digital output, HTTP, SMTP, FTP and
NAS server
File upload via HTTP, SMTP, FTP and NAS server
General
Smart Focus System Remote focus
Connectors
RJ-45 for Network/PoE connection
Audio input/output
AV output
AC 24V power input
DC 12V power input
Digital input*1
Digital output*1
LED Indicator System power and status indicator
Power Input
DC12 V/A C24 V
IEEE 802.3af PoE
Power Consumption
DC 12V: Max. 8 W
AC 24V: Max. 8.8 W
PoE: Max. 10.6 W
Dimensions Ø: 157 mm x 109 mm
Weight Net: 758g
Safety Certifications CE, LVD, FCC Class B, VCCI, C-Tick, UL
Operating Temperature
Starting Temperature: -10°C ~ 50°C (14°F~ 122°F)
Working Temperature: -20°C ~ 50°C (-4°F~ 122°F)
Warranty 24 months
System Requirements
Operating System Microsoft Windows 7/Vista/XP/2000
Web Browser
Mozilla Firefox 7~10 (streaming only)
Internet Explorer 7/8/9/10/11
Other Players
VLC: 1.1.11 or above
Quicktime: 7 or above
Included Accessories
CD
User's manual, quick installation guide, Installation Wizard 2,
ST7501 32-channel recording software
Others
Quick installation guide, warranty card, alignment sticker,
L-type hex key wrench, screws, hex nut, AV cable, power cable
Dimensions
AM -215
L Shape Bracket
Mounting Kits
AM-516
Adaptor Ring
AM-520
Mounting Adaptor
Ø157 mm
Ø61 mm
109 mm
