Vivotek FD8163 Quick Installation Guide

EN - 3
English
Hardware Installation
3
FD8163
50
50
5m
41
41
5m
Before installing your camera,
make sure the built-in PIR (Passive
Infrared Sensor) can be directed
toward the area of interest, where
possible intrusion may occur. (The
sensitivity of PIR sensor depends
on the object size and temperature
differences between the object and
the background environment.)
Dome Cover
Bottom of the Camera
Top View
Side View
LCD Monitor/
Camera tester
AV Out
NOTE:
You may use the included AV cable to connect a camera tester for initial conguration at
the installation site.
Remove the dome cover using the included T10 Torx
screwdriver. You should then jot down the MAC address
at the bottom of the camera.
