EN - 8
When mounting the camera, you can use the key hole slot at the bottom. The key hole
slot helps facilitate installation and a safe mounting.
1. First fasten a pioneer screw to the wall/ceiling. Mount the camera to the screw.
2. Use a pencil to mark the locations of the 3 permanent mounting holes.
3. When cabling and the initial adjustment is done, mount the camera by fastening
screws to the 3 mounting holes.
Mounting Holes
Key Hole Slot
Pioneer Screw
NOTE:
3. You may also push the Auto Focus button on the
camera to obtain the same results especially when
you are using camera tester for onsite adjustment.
To Next Page
