VIVOTEK
User's Manual - 9
4. You may drill a cabling hole for routing the cables. You can then hang the camera to the
screws by passing them through the key slot holes.
77.3°
121°
5M
5M
Consider the effective range and the shooting angles of the PIR when determining the
mounting position of the camera.
A
4
