VIVOTEK
User's Manual - 109
■ Add date and time sufx to the le name. Select this option to add a date/time sufx to the le name.
For example:
Click Save media to enable the settings, then click Close to exit the Add media page.
After you set up the rst media server, a new column for media server will automatically display on the
Media list. If you wish to add more media options, click Add media.
Media type -
Video clip
Select to send video clips when a trigger is activated.
■ Media name: Enter a name for the media setting.
■ Source: Select the source of video clip from which channel and stream number.
■ Pre-event recording
The Network Camera has a buffer area; it temporarily holds data up to a certain limit. Enter a number
to decide the duration of recording before a trigger is activated. Up to 9 seconds of video can be
recorded.
Snapshot_20150720_100341
Date and time suffix
The format is: YYYYMMDD_HHMMSS
File name prefix
