Vivotek FD816C-HF2 User Manual

VIVOTEK
User's Manual - 305
Technical Specications
Model FD816 C- HF2
System Information
CPU Multimedia SoC (System-on-Chip)
Flash 128 MB
RAM 256MB
Camera Features
Image Sensor 1/2.8" Progressive CMOS
Maximum Resolution 1920x1080 (2MP)
Lens Type Fixed-focal
Focal Length 2.8 mm
Aperture F1.8
Field of View
109° (horizontal)
61° (vertical)
132° (diagonal)
Shutter Time 1/5 sec. to 1/32,000 sec.
WDR Technology WDR Pro
Minimum Illumination 0.07 Lux @ F1.8 (Color)
Pan/tilt/zoom Functionalities
ePTZ:
4x digital zoom IE plug-in
On-board Storage MicroSD/SDHC/SDXC card slot
Video
Compression H.264 & MJPEG
Maximum Frame Rate 30 fps @ 1920x1080
Maximum Streams 3 simultaneous streams
S/N Ratio 58.48 dB
Dynamic Range 100 dB
Video Streaming Adjustable resolution, quality and bitrate
Image Settings
Adjustable image size, quality and bit rate; Time stamp, text
overlay, flip & mirror; Configurable brightness, contrast,
saturation, sharpness, white balance, exposure control,
gain, backlight compensation, privacy masks; Scheduled
profile settings, Smart Stream, 3DNR
Audio
Audio Capability Audio input
Compression G.711, G.726
Interface Buit-in Microphone
Effective Range 5 Meters
Network
Users Live viewing for up to 10 clients
Technical Specifications
Protocols
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP,
IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS,
SNMP, 802.1X, UDP, ICMP, ARP, SSL, TLS
Interface
10Base-T/100BaseTX Ethernet (RJ-45)
*It is highly recommended to use standard Cat. 5e & Cat. 6
cables which are compliant with the 3P/ETL standard.
ONVIF Supported, specification available at ww w.onvif.org
Intelligent Video
Video Motion Detection Five-window video motion detection
Alarm and Event
Alarm Triggers
Video motion detection, manual trigger, periodical trigger,
system boot, recording notification, camera tampering
detection, audio detection
Alarm Events
Event notification using HTTP, SMTP, FTP and NAS server,
SD Card
File upload via HTTP, SMTP, FTP, NAS server and SD card
General
Connectors RJ-45 for Network/PoE connection
LED Indicator System power and status indicator
Power Input IEEE 802.3af PoE Class 1
Power Consumption Max. 3.3W
Dimensions Ø 60 x 115 mm
Weight Net: 138g
Safety Certifications CE, LVD, FCC Class B, VCCI, C-Tick
Operating Temperature
Starting Temperature: 0°C ~ 45°C (32°F ~ 113°F)
Working Temperature: 0°C ~ 45°C (32°F ~ 113°F)
Warranty 24 months
System Requirements
Operating System Microsoft Windows 8/7/Vista/XP/2000
Web Browser
Mozilla Firefox 7~10 (streaming only)
Internet Explorer 7/8/9/10/11
Other Players
VLC: 1.1.11 or above
QuickTime: 7 or above
Included Accessories
Others Quick installation guide
Dimensions
60 mm 115 m m
118 m m
6F, No.192, Lien-Cheng Rd., Chung-Ho,
New Taipei City, 235, Taiwan, R.O.C.
T: +886-2-82455282 F: +886-2-82455532
E: sales@vivotek.com
VIVOTEK INC.
2050 Ringwood Avenue,
San Jose, CA 95131
T: 408-773-8686 F: 408-773-8298
E: salesusa@vivotek.com
VIVOTEK USA
Ver. 10
All specifications are subject to change without notice. Copyright © VIVOTEK INC. All rights reser ved.
Randstad 22-133, 1316BW Almere,
The Netherlands
T: +31(0)36 -5298- 434
E: saleseurope@vivotek.com
VIVOTEK Europe
602, Best sky Tower, Plot No. F-5,
Netaji Subhash Place, Pitam Pura, Delhi-110 034
T: +91-11-45137465
E: salesindia@vivotek.com
VIVOTEK India
