Vivotek FD816C-HF2 User Manual

VIVOTEK
User's Manual - 9
5. The retention clips will hold the module in place.
6. Note that the shooting angle of a xed lens can only be vertically adjusted. This mark should
be on top. There is no need to change the shooting angle for the sheye lens model.
5
6
6-1. Use a small-size Phillips screwdriver to change the shooting angle of a xed focal lens.
6-2. Attach the top cover to camera by aligning the notch. The magnets will hold the cover in
place.

Vivotek FD816C-HF2 Specifications

General

Brand	Vivotek
Model	FD816C-HF2
Category	Security Camera
Language	English
