VIVOTEK
20 - User's Manual
Ready to Use
1. A browser session with the Network Camera should prompt as shown below.
2. You should be able to see live video from your camera. You may also install the 32-channel
recording software from the software CD in a deployment consisting of multiple cameras. For
its installation details, please refer to its related documents.
To adjust the viewing angle -- 3-axis mechanism design
1. Loosen the tilt adjustment screws and then turn the lens module up or down. Upon
completion, tighten the screw.
2. Turn the lens to adjust the image orientation.
Horizontal Pan 350°
Lens Horizontal Pan 350°
Vertical Tilt 65°
Tilt Adjustment
Screws
1
2
