Vivotek FD9367-HTV User Manual

VIVOTEK
240 - User's Manual
0 ~ W,0 ~ H
W: 0~ The current
image width -1
H: 0~ The current
image height -1
"capability_image_c<0~(n-1)>_privacymask
_wintype" = polygon.
* Only available when px is listed in
"capability_image_c<0~(n-1)>_privacymask
_windomain".
win_i<0~(m-1)>_polygo
nstd
0 ~ 9999,0 ~ 9999,
0 ~ 9999,0 ~ 9999,
0 ~ 9999,0 ~ 9999,
0 ~ 9999,0 ~ 9999
4/4 Coordinate of polygon window position.
(4 points: x0,y0,x1,y1,x2,y2,x3,y3)
* Only available when
"capability_image_c<0~(n-1)>_privacymask
_wintype" = polygon.
* Only available when std is listed in
"capability_image_c<0~(n-1)>_privacymask
_windomain".
7.26 3D Privacy mask
Group: privacymask3d_c<0~(n-1)> for n channel products and m privacy mask window.
(capability_image_c<0~(n-1)>_privacymask_wintype = 3Drectangle)
n denotes the value of "capability_nvideoin" and m denotes the value of
"capability_videoin_c<0~(n-1)>_nprivacymask"
NAME VALUE SECURITY
(get/set)
DESCRIPTION
enable <boolean> 4/4 Enable the 3D privacy mask
color 0~"
capability_image_c<0~(n-1)
>_privacymask_ncolor"-1
4/4 Privacy mask color
win_i<0~(m-1)>_name string[40] 4/4 Name of the privacy mask window.
win_i<0~(m-1)>_pan "capability_ptz_c<0~(n-1)>
_minpan" ~
"capability_ptz_c<0~(n-1)>
_maxpan"
4/4 Pan position of window position.
* Only available when bit0 of
"capability_camctrl_c<0~(n-1)>_buil
dinpt" is "1"
win_i<0~(m-1)>_tilt "capability_ptz_c<0~(n-1)>
_mintilt" ~
"capability_ptz_c<0~(n-1)>
_maxtilt"
4/4 Tilt position of window position.
* Only available when bit1 of
"capability_camctrl_c<0~(n-1)>_buil
dinpt" is "1"
win_i<0~(m-1)>_zoom "capability_ptz_c<0~(n-1)>
_minzoom" ~
4/4 Zoom position of window position.
