Technical Specications
Model FD9167-H
System Information
CPU Multimedia SoC (System-on-Chip)
Flash 128MB
RAM 512MB
Camera Features
Image Sensor 1/2.8" Progressive CMOS
Maximum Resolution 1920x108 0
Lens Type Fixed-focus
Focal Length f = 2.8 mm
Aperture F1.6
Auto-iris Fixed-iris
Field of View
109° (Horizontal)
61° (Vertical)
126° (Diagonal)
Shutter Time 1/5 sec. to 1/32,000 sec.
WDR Technology WDR Pro
Day/Night
Removable IR-cut lter for day & night
function
Minimum Illumination
0.07 Lux @ F1.6 (Color)
0.001 Lux @ F1.6 (B/W)
0 Lux with IR illumination on
Pan Range 350°
Tilt Range 70°
Rotation Range 180°
Pan/Tilt/Zoom
Functionalities
ePTZ:48x digital zoom
(4x on IE plug-in, 12x built in)
IR Illuminators
Built-in IR illuminators, effective up to 30
meters with Smart IR, IR LED*2
On-board Storage
Slot type: MicroSD/SDHC/SDXC card slot
Seamless Recording
Video
Compression H.265, H.264, MJPEG
Maximum Frame Rate 30 fps @ 1920x1080
Maximum Streams 3 simultaneous streams
S/N Ratio 58 dB
Dynamic Range 120 dB
Video Streaming
Adjustable resolution, quality and constant
bit rate control; Smart Stream III
Image Settings
Time stamp, text overlay, ip & mirror;
Congurable brightness, contrast,
saturation, sharpness, white balance,
exposure control, gain, backlight
compensation, privacy masks; Scheduled
prole settings, video rotation, 3DNR, DIS,
HLC
Audio
Audio Capability Two-way audio
Compression G.711, G.726
Interface
Built-in Mic
External Mic input
External line output
Effective Range 5 meters
Network
Users Live viewing for up to 10 clients
Protocols
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/
RTP/RTCP, IGMP, CIFS/SMB, SMTP, FTP, DHCP,
NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP,
802.1X, UDP, ICMP, ARP, SSL/ TLS, NTCIP
Interface
10 Base-T/100 Base-TX Ethernet (RJ-45)
*It is highly recommended to use standard
CAT5e & CAT6 cables which are compliant
with the 3P/ETL standard.
ONVIF
Supported, specication available at
www.onvif.org
Intelligent Video
Video Motion Detection Five-window video motion detection
Alarm and Event
Alarm Triggers
Motion detection, manual trigger, digital
input, periodical trigger, system boot,
recording notication, camera tampering
detection, audio detection, MicroSD card
life expectancy
Alarm Events
Event notication using digital output, HTTP,
SMTP, FTP, NAS server and MicroSD card
File upload via HTTP, SMTP, FTP, NAS server
and MicroSD card
General
Connectors
RJ-45 cable connector for Network 10/100
Mbps PoE connection
Audio Mic in
Audio line out
DC 12V
Digital input *1
Digital output *1
LED Indicator System power and status indicator
Power Input
DC 12V
IEEE 802.3af PoE Class 0
Power Consumption Max. 7 W
Dimensions Ø 139 x 104 mm
Weight 459 g
Safety Certications CE, LVD, FCC Class B, VCCI, C-Tick, UL
Technical Specications
Compatible Accessories
All specications are subject to change without notice. Copyright © VIVOTEK INC. All rights reserved. Ver. 2
6F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C. | T: +886-2-82455282 | F: +886-2-82455532 | E: sales@vivotek.com | W: www.vivotek.com
Operating Temperature
Starting Temperature:
0°C ~ 50°C (32°F ~ 122°F)
Working Temperature:
-10°C ~ 50°C (14°F ~ 122°F)
Humidity 90%
Warranty 24 months
System Requirements
Operating System Microsoft Windows 8/7
Web Browser
Mozilla Firefox 7~43 (streaming only)
Internet Explorer 10/11
Other Players
VLC: 1.1.11 or above
Quicktime: 7 or above
Included Accessories
Others
Quick installation guide, warranty card,
screw pack, alignment sticker
Dimensions
Ø 139 mm
104 mm
Mounting Kits
AM-21A AM-514
L-shape Bracket Adapting Plate
