Vivotek FD9391-EHTV User Manual

VIVOTEK
6 - User's Manual
Ethernet 10/100 RJ45 Plug
Some of the sufx syntax used in model naming are listed below:
E w/ heater for extreme weather
Fx Focal length w/ number
T w/ Remote focus lens
R w/ PoE repeater
H w/ High Dynamic Range functionality
NOTE:
Hardware Installation
0002D10766AD
XXXXXX
1
1. Jot down the camera's MAC address for later reference.
IMPORTANT:
The FD9391-EHTV comes with an embedded heater and requires an 802.3at PoE
switch.
Operating
Temperature
Consumption & Power Input
≥-50ºC PoE: 24.8W (PoE Plus mid-span or switch, 42.5V-57V - 0.58A-0.435A);
AC 24V input: 21.8W [1.65A (PF0.55)]; DC 12V: 19.5W (1.625A)
IMPORTANT:
If DC power is preferred, it should comply with: O/P: 12VDC, 1A or 2A min., L.P.S. per IEC
60950-1.
Si l'alimentation CC est préférable, elle devrait être conforme avec ce qui suit : Sortie : 12
VCC, 2 A min., alimentation limitée à conformité CEI 60950-1.
