Vivotek FE8174V User Manual

VIVOTEK
User's Manual - 33
Video Stream: This Network Cmera supports multiple streams (stream #1 ~ #3) simultaneously. You
can select any one of them for live viewing. For more information about multiple streams, please refer to
page 63 for detailed information.
Manual Trigger: Click to manually enable or disable an event trigger. Please congure an event setting
before enabling this function. A total of 3 or 4 event settings can be congured. For more information
about event setting, please refer to page 103. If you want to hide this item on the homepage, please go
to the System > Homepage Layout > General settings > Customized button to deselect the “show
manual trigger button” checkbox.
Digital Output: Click to turn the digital output device on or off.
PTZ Control Panel:
Pano.: Click this button to start the automated circular rotation through a regional view (360° continuous
rotation). Note that this function does not apply in a Panoramic view because a Panoramic view already
shows the full coverage.
Stop: Click this button to stop the Auto Pano and Auto Rotate functions.
Pan /Tilt /Zoom /Panoramic/Rotate speed: Adjust the speed of these controls when exerted:
Left
Down
Zoom Out
Start to Auto Pano
Stop Auto Pano
Return to Home Position
Right
Up
Zoom In
Pan speed Tilt speed Zoom speed Panoramic
speed
Rotate speed
-5 -5 -5 - - Slower
Faster
-4 -4 -4 - -
-3 -3 -3 - -
-2 -2 -2 - -
-1 -1 -1 - -
0 0 0 0 0
1 1 1 1 1
2 2 2 2 2
3 3 3 3 3
4 4 4 4 4
5 5 5 5 5
IMPORTANT:
The PTZ panel will not appear if you congure a video stream to be using the "Local dewarp"
feature. To change the shooting direction of a locally-dewarped regional view, please refer to
page 101 "PTZ panel" for details.
