Vivotek FE8174V - Physical Description

VIVOTEK
6 - User's Manual
Physical Description
Inner View
Header (J7)
Spring Contacts (A)
Lens
Contacts for Internal Microphone (B
)
Header (J6)
Ethernet 10/100 RJ45 Socket
i
Align (B) to (A) when attaching the
dome cover
MicroSD/SDHC/SDXC Card Slot
Reset Button
Status LEDs
