11
8.1 – OSD Menu Functions
Main Menu Sub-Menu Options Description
Game
Settings
Standard Mode On / Off Turn on or off Standard mode
RTS / RPG
Mode
On / Off Turn on or off RTS / RPG mode
FPS Arena
Mode
On / Off Turn on or off FPS mode
MOBA Arena
Mode
On / Off Turn on or off MOBA mode
Adaptive-Sync On / Off Turn the Adaptive Sync function on/off
Shadow
Balance
0-100 Adjust shadow balance value
Response Time Off, Normal, Fast,
Ultrafast
Set the response time options
Refresh Rate On, Off Turn on or off Refresh rate function
Position When it is “on” status, set the
positions: Top Right, Top Left, Bottom
Right, Bottom Left
Game
Crosshair
On, Off Turn on or off Game Crosshair
function
Game Time On, Off Turn on or off Game Time function
Position Set positions: Top Right, Top Left,
Bottom Right, Bottom Left
Dynamic
Brightness
Off, Normal, Expert,
Elaboration
Turn off Dynamic function or set a
kind of dynamic brightness
MPRT On, Off Turn off HDR function, or set as HDR
standard display.
Ambient
Lighting
On, Off Turn on or off Ambient Lighting
function
Settings
Brightness 0~100 Adjust display brightness
Contrast 0~100 Adjust display contrast
DCR On, Off Turn on or off DCR function
Contextual
Model
Off, Movie, Reading,
Night
Turn off contextual model function or
set a model as: Movie, Reading, or
Night
Low Blue Light 0~100 Set blue light ltering level (0 is off)
Sharpness 0~5 Set display sharpness
Gamma 1.8, 2.0, 2.2, 2.4, 2.6,
S.curve
Adjust the relationship between
a pixel in the source input and its
brightness on the display (gamma 2.2
is standard)
Aspect Ratio Wide Screen, 4:3, 1:1,
Auto
Select on-screen aspect ratio

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vivotek GFV24CB2 and is the answer not in the manual?

Vivotek GFV24CB2 Specifications

General IconGeneral
Model NumberGFV24CB2
LED IndicatorPower on: Blue (solid); Power saving: Red (solid)
Screen Size23.8’’
Viewing Angle178° (H) / 178° (V)
Aspect Ratio16:9
Resolution1920x1080p
Refresh Rate180Hz
BrightnessTypical: 250 cd/m2
Default Color Temperature6500
Color Gamut95% sRGB; 85% NTSC
Pixel Pitch0.0915 x 0.2745 mm
Display Colors16.7M
Response Time6ms (OD)/MPRT 1ms
PortsDP1.2 x 1, HDMI 1.4 x 1, Audio output x 1
AdapterDC 12V 2.5 A
Power ConsumptionTypical: 24W; Max: 34W; Standby ≤ 0.5W
OSD Language*English, 简体中文,Nederlands, Français, Deutsch 한국,Español, Русский, Português, Turkce, Italiano, Polski, 日本語
Usage Temp.32°F~104°F (Operating), -4°F~ 140°F (Storage), 10- 85% RH (Non-Condensing)
Weight and Dimensions IconWeight and Dimensions
Tilt AngleForward 5°; Backward 15° (±2°)
VESA Mounting75 x 75 mm
Dimensions (with stand)21.3 x 15.9 x 6.3 in (542.4 x 402.8 x 160.9mm)
Weight (with stand)7.05 lb. / 9.92 lb. (with packaging)
