Vivotek GFV24CB2 User Manual

7
Section 4: Stand Installation
1. Open the package and take out the product with foam still attached. Gently place
it on a desktop or table.
2. Take out the stand stem and attach the stand stem into the opening on the back,
then use the included screwdriver and two screws to fasten the stand stem to the
monitor.
Screws x2
Stand Stem
3. Attach the stand base to the bottom of stand stem, and use two more screws
to fasten the stand base to the stand stem. Then remove the monitor from the
remaining foam section and stand it up on the desired surface.
Screws x2
Stand Base
If needed, the stand can easily be detached from the monitor by removing the
screws on the back of the monitor.

Vivotek GFV24CB2 Specifications

General

Model Number	GFV24CB2
LED Indicator	Power on: Blue (solid); Power saving: Red (solid)
Screen Size	23.8’’
Viewing Angle	178° (H) / 178° (V)
Aspect Ratio	16:9
Resolution	1920x1080p
Refresh Rate	180Hz
Brightness	Typical: 250 cd/m2
Default Color Temperature	6500
Color Gamut	95% sRGB; 85% NTSC
Pixel Pitch	0.0915 x 0.2745 mm
Display Colors	16.7M
Response Time	6ms (OD)/MPRT 1ms
Ports	DP1.2 x 1, HDMI 1.4 x 1, Audio output x 1
Adapter	DC 12V 2.5 A
Power Consumption	Typical: 24W; Max: 34W; Standby ≤ 0.5W
OSD Language*	English, 简体中文，Nederlands, Français, Deutsch 한국，Español, Русский, Português, Turkce, Italiano, Polski, 日本語
Usage Temp.	32°F~104°F (Operating), -4°F~ 140°F (Storage), 10- 85% RH (Non-Condensing)

Weight and Dimensions

Tilt Angle	Forward 5°; Backward 15° (±2°)
VESA Mounting	75 x 75 mm
Dimensions (with stand)	21.3 x 15.9 x 6.3 in (542.4 x 402.8 x 160.9mm)
Weight (with stand)	7.05 lb. / 9.92 lb. (with packaging)
