Network Deployment
1� If you have external devices such as sensors and alarms, make connections from
general I/O terminal block�
LAN Connection
POWER
COLLISION
LINK
RECEIV E
PARTITION
1
2
3
4
5
3� Connect the supplied power cable from
the camera to a power outlet�
2� Connect the camera to a switch via
Ethernet cable�
Non-PoE Switch
