Vivotek IP8130 - Privacy Mask

VIVOTEK
154 - User's Manual
URL Command Document for All SeriesIP8130/31
39
theme_color_configbackground string[7] # 323232 1/6 Background color of
configuration area.
theme_color_videobackground string[7] # 565656 1/6 Background color of video area.
theme_color_case string[7] # 323232 1/6 Frame color
custombutton_manualtrigger_s
how
<boolean> 1 1/6 Show or hide manual trigger
(VI) button in homepage
0 -> Hidden
1 -> Visible
7.21 Privacy mask
Group: privacymask_c<0~(n-1)> for n channel product
NAME VALUE DEFAULT SECURITY
(get/set)
DESCRIPTION
enable <boolean> 0 4/4 Enable privacy mask.
win_i<0~4>_enable <boolean> 0 4/4 Enable privacy mask
window.
win_i<0~4>_name string[40] <blank> 4/4 Name of the privacy mask
window.
win_i<0~4>_left 0 ~ 320 0 4/4 Left coordinate of window
position.
win_i<0~4>_top 0 ~ 240 0 4/4 Top coordinate of window
position.
win_i<0~4>_width 0 ~ 320 0 4/4 Width of privacy mask
window.
win_i<0~4>_height 0 ~ 240 0 4/4 Height of privacy mask
window.
