Rear Panel
The back panels are identical for both models.
Power Cord
Socket
Reset Button
Ethernet 10/100
RJ45 Socket
General I/O
Terminal Block
1 DI-
2 DI+
3 Audio GND
4 Audio Out
Audio out cable is user-supplied�
