Vivotek MD7560 User Manual

VIVOTEK
18 - User's Manual
Main Page
This chapter explains the layout of the main page. It is composed of the following sections:
VIVOTEK INC� Logo, Host Name, Camera Control Area, Configuration Area, Menu, and Live
Video Window�
VIVOTEK INC. Logo
Click this logo to visit the VIVOTEK website�
Host Name
The host name can be customized to t your needs. For more information, please refer to System on
page 25�
Camera Control Area
Video Stream: MD7530/7530D supports dual streams (stream 1 ~ 2) simultaneously and MD7560/7560D
supports multiple streams (stream 1 ~ 4) simultaneously� You can select either one for live viewing� For
more information about dual/multiple streams, please refer to page 58 for detailed information�
Manual Trigger: Click to enable/disable an event trigger manually� Please configure an event setting
on Application page before enable this function� A total of 3 event settings can be congured. For more
information about event setting, please refer to page 74�
If you want to hide this item on the homepage, please go to the Homepage Layout page to uncheck “show
manual trigger button�“ Please refer to page 71 for detailed illustration�
PTZ Panel (MD7560/7560D only): This Network Camera supports “digital“ (e-PTZ) pan/tilt/zoom control�
Please refer to Camera Control on page 67 for detailed information�
VIVOTEK INC. Logo
Camera Control Area
Configuration Area
Host Name
Live View
Window
Resize Buttons
Hide Button
