VIVOTEK
User's Manual - 61
Video Quality Settings
Advanced Mode
Click the stream item to display the detailed information� This Network Camera offers real-time MPEG-4
and MJEPG compression standards (Dual Codec) for real-time viewing.
The MD7530/7530D supports dual streams with frame size ranging from 176 x 144 to 640 x 480.
The MD7560/7560D supports multiple streams with frame size ranging from 176 x 144 to 1600 x 1200.
The maximum frame size will follow your settings in the above Viewing Window sections.
If MPEG-4 mode is selected, the video is streamed via RTSP protocol� There are four parameters
provided in MPEG-4 mode which allow you to adjust the video performance:
■ Frame size
You can set up different video resolution for different viewing devices. For example, set a smaller
frame size and lower bit rate for remote viewing on mobile phones and a larger video size and a higher
bit rate for live viewing on web browsers� Note that a larger frame size takes up more bandwidth�
■ Maximum frame rate
This limits the maximum refresh frame rate per second. Set the frame rate higher for smoother video
quality�
If the power line frequency is set to 50Hz, the frame rates are selectable at 1fps, 2fps, 3fps, 5fps,
8fps, 10fps, 15fps, 20fps, and 25fps� If the power line frequency is set to 60Hz, the frame rates are
selectable at 1fps, 2fps, 3fps, 5fps, 8fps, 10fps, 15fps, 20fps, 25fps, and 30fps� You can also select
Customize and manually enter a value� The frame rate will decrease if you select a higher resolution�
