Physical Description
Inner View
Outer View
General I/O Terminal Block
This Network Camera provides a general I/O terminal block which is used to connect external
input / output devices. The pin denitions are described below.
SD/SDHC Card Capacity
This network camera is compliant with MicroSD/SDHC 32GB and other preceding standard SD
cards.
Pin Name
+ Digital input +
- Digital input -
Screw Holes
Lens
MicroSD/SDHC Card Slot
Reset Button
Status LED
Waterproof Level: IP67
Power Cord Socket (black)
Ethernet 10/100 RJ45 Plug
Microphone In (pink)
General I/O Terminal Block
MD8562 (PoE)
MD8562D (PC power)
