User's Manual - 7
Installing the Ground Wire
As shown in the gure below, secure one side of the supplied ground wire to the screw hole,
route the wire, and attach the other end to a junction box or a grounded conduit.
Network Deployment
Setting up the Network Camera over the Internet
General Connection (without PoE) (MD8562D)
1. If you have external devices such as sensors and alarms, connect them to the general I/O
terminal block.
2. Connect the camera to a switch via Ethernet cable.
3. Connect the power cable from the Network Camera to a power outlet.
+ : Digital input
- : Digital input
POW
ER
C
O
LL
I
S
ION
L
I
N
K
RE
CEIVE
PARTITIO
N
1
2
3
4
5
2
3
Ethernet Switch
1
NOTE:
The power adapter should comply with
L.P.S. regulations featuring O/P: 12V
DC, 1.5A min.

Vivotek MD8562 Specifications

General

Brand	Vivotek
Model	MD8562
Category	Security Camera
Language	English
