VIVOTEK
User's Manual - 71
► All the items in the “Region of Interest” cannot be greater than the “Output Frame Size“ (current
maximum resolution).
■ The parameters of the multiple streams:
When completed with the settings in the Viewing Window, click Save to enable the settings and click
Close to exit the window. The selected Output Frame Size will immediately be applied to the Frame
size of each video stream. Then you can go back to the home page to test the e-PTZ function. For more
information about the e-PTZ function, please refer to page 83.
Region of Interest Output frame size
Stream 1 1920 X 1080 ~ 176 x 144 (Selectable) 1920 X 1080 ~ 176 x 144 (Selectable)
Stream 2 1920 X 1080 ~ 176 x 144 (Selectable) 1920 X 1080 ~ 176 x 144 (Selectable)
Stream 3 1920 X 1080 ~ 176 x 144 (Selectable) 1920 X 1080 ~ 176 x 144 (Selectable)
Stream 4 1920 X 1080 (Fixed) 1920 X 1080 ~ 176 x 144 (Selectable)
NOTE:
► All the items in the “Region of Interest” cannot be greater than the “Output Frame Size“ (current
maximum resolution).
■ The parameters of the multiple streams:
When completed with the settings in the Viewing Window, click Save to enable the settings and click
Close to exit the window. The selected Output Frame Size will immediately be applied to the Frame
size of each video stream. Then you can go back to the home page to test the e-PTZ function. For more
information about the e-PTZ function, please refer to page 83.
Output Frame Size
(Size of the Live View Window)
Region of Interest
(Viewing Region)
To Next Page
