Physical Description
2
Front View
Rear View
Disk 1
Disk 2
HDD LED
Power
button & LED
Reset button
RS-232 (reserved) LAN
WAN
VGA
USB2
combo
USB1
combo
eSATA
MIC-In
Line Out
Line In
DC Power
Fan exhaust
outlet
IMPORTANT:
It is important to leave a clearance of
15cm to the rear side of the chassis.
The clearance is required to ensure an
adequate airow through the chassis to
ventilate heat. A 5cm clearance is also
required on both sides of the chassis.
To ensure normal operation, maintain
ambient airow. Do not block the airow
around chassis such as placing the sys-
tem in a closed cabinet.
15cm
5cm
5cm
5cm
