CONTROL & FUNCTION
• Brake cable adjustments
• Front brake lever
• Rear brake lever
• Throttle grip: Turn toward
rider for higher speed
• Throttle cable adjustment
• Seat adjustment: Adjust seat setting
angle and tighten firmly.
• Seat height quick-release lever: With
lever turned upward, adjust the height of
upper seat post. Tighten the nut firmly
then press lever down to lock seat
height. Do not exceed seat height
extension limit as marked on post.
• Lower seat post adjustment knob: The
bottom of the lower seat post is cut
diagonally and stabilized by weight.
Push seat post all the way down and
tighten knob firmly by hand. If not
tightened completely, it becomes
dangerous when riding or pulling up by
seat post.
HANDLE BARS
SEAT
