Adjusting the Color Calibration Settings
Color Calibration Settings allow you to make precise adjustments to
the picture and to create picture modes to save groups of picture
settings.
The Color Tuner, 11 Point White Balance, and test
patterns allow technicians to manually calibrate the TV.
Calibration requires specialized training, an input with
precisely set colors, and a specialized light meter.
To adjust the color calibration picture settings:
1. From the PICTURE menu, use
the Arrow buttons to highlight
Color Calibration and press
the OK button. The COLOR
CALIBRATION menu is displayed.
2. Use the Arrow buttons to
highlight the setting you wish to
adjust, then press the OK button
to change the setting:
• Picture Mode - Not directly
selectable (reference only).
Changes to Hue, Saturation,
and Brightness are saved
here and indicated with an
asterisk (*).
• Color Temperature - Not directly selectable (reference
RQO\&KDQJHVWR2΍VHWDQG*DLQDUHVDYHGKHUHDQG
indicated with an asterisk (*).
• Color Tuner$GMXVWWKH+6%FRORU5*%R΍VHWVDQG
11-point white balance, and display calibration test
patterns.
• Reset Color Tuner/Temperature - Prevent/allow changes to
the currently selected custom picture mode.
VI
ZI
O
COLOR CALIBRATION
Picture Mode*
Color Temperature*
Color Tuner
Reset Color Temperature
Adjusting the Color Tuner Settings
The Color Tuner settings allow you to adjust the Hue, Saturation,
and Brightness (HSB) color and 11 point white balance, turn color
FKDQQHOV R΍IRU WHVWLQJ DQGGLVSOD\ FRORUEDUȵDWDQGUDPSWHVW
patterns.
To adjust the HSB color settings:
1. From the PICTURE menu, use the Arrow buttons to highlight
Color Calibration and press the OK button. The COLOR
CALIBRATION menu is displayed.
2. Use the Arrow buttons to highlight Color Tuner, and press the
OK button. The Color Tuner menu is displayed.
3. Use the Arrow buttons on the remote to highlight the Hue,
Saturation, Brightness, (these 3 adjust the color) 2΍VHW, or
Gain (these two adjust the color temperature) of the color you
wish to adjust. Press the OK button.
4. Use the Left/Right Arrow buttons to adjust the value. When
\RXDUHȴQLVKHGSUHVVWKHOK button to save the setting.
5. :KHQ\RXKDYHȴQLVKHGDGMXVWLQJWKH&RORU7XQHUVHWWLQJV
press the BACK button to adjust additional settings or EXIT.
When Hue, Saturation, or Brightness have been changed, an
DVWHULVNbDSSHDUVDIWHUWKHQDPHRIWKH3LFWXUH0RGH
:KHQ 2΍VHW RU *DLQ KDYH EHHQ FKDQJHG DQ DVWHULVN  DSSHDUV
after the name of the Color Temperature.
Color Tuner
Red Green Blue Cyan Magenta Yellow
Hue 0 0 0 0 25 -14
Saturation -1 5 -4 0 -2 0
Brightness -24 0 -22 0 0 0
Offset 0 0 0
Gain 0 0 0

Vizio E55-C1 Specifications

General

Color depth	8 bit
Screen shape	Flat
Response time	- ms
Display diagonal	54.6 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Full-Array
Supported video modes	1080p
Contrast ratio (dynamic)	500000:1
Display refresh rates supported	120 Hz
Motion interpolation technology	-
Music apps	Pandora, Spotify
Video apps	Netflix, YouTube
Lifestyle apps	Facebook, Twitter
Audio decoders	DTS Studio Sound
RMS rated power	10 W
Number of speakers	2
PC in (D-Sub)	No
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Wi-Fi standards	Wi-Fi 4 (802.11n)
On Screen Display (OSD) languages	ENG, ESP, FRE
Product color	Black
Panel mounting interface	300 x 300 mm
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Package depth	160 mm
Package width	1357 mm
Package height	821.9 mm
Package weight	21000 g
Sustainability certificates	ENERGY STAR
Certification	UL, cUL, NOM, FCC Class B, BET7/ICES-003 Class B, IC, IFETEL, HDMI (CEC, ARC), Dolby Digital

Weight and Dimensions

Stand width	1090 mm
Depth (with stand)	255 mm
Height (with stand)	781 mm
Weight (with stand)	15900 g
Depth (without stand)	64.01 mm
Width (without stand)	1239 mm
Height (without stand)	721.1 mm
Weight (without stand)	15500 g
