Vizio E60-C3 Service Manual

35
<External input USB>No picture on the display (7)
Does not the picture display when USB cable plugged into USB port?
Main UNIT:
Is USB stick video format correct?
Is the USB +5V sent to pin (1) of
CN6500?
YES
Change to correct .jpg or .jpeg or .png or
.bmp format.
NO
NO
Check the U6500 power manager V-in
and V-out and power enable function.
Is the USB con (CN6500) signal properly
sent to pin (T25) (USB_DM_P1) and pin
pin (T24) (USB_DP_P1) of IC U107?
YES
Refer to “The picture doesn't appear in
all modes.”
NO
Check the circuit between CN6500 and
IC U107
YES

Vizio E60-C3 Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Full-Array
Supported video modes	1080p
Contrast ratio (dynamic)	5000000:1
Viewing angle, horizontal	176 °
Display refresh rates supported	120 Hz
Motion interpolation technology	-
Music apps	Pandora, Spotify
Video apps	Netflix, YouTube
Lifestyle apps	Facebook, Twitter
Audio decoders	DTS Studio Sound
RMS rated power	10 W
Number of speakers	2
PC in (D-Sub)	No
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Wi-Fi standards	Wi-Fi 4 (802.11n)
On Screen Display (OSD) languages	ENG, ESP, FRE
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Package depth	172 mm
Package width	1447 mm
Package height	902 mm
Package weight	25400 g
Sustainability certificates	ENERGY STAR
Certification	UL, cUL, FCC Class B, BET7/ICES-003 Class B, IC, HDMI (CEC, ARC), Dolby Digital

Weight and Dimensions

Stand width	1186 mm
Depth (with stand)	279.9 mm
Height (with stand)	851.4 mm
Weight (with stand)	21000 g
Depth (without stand)	64.26 mm
Width (without stand)	1353 mm
Height (without stand)	786.4 mm
Weight (without stand)	20600 g
