Vizio E60-C3 Service Manual

36
<External Input (Component)>No picture on the display (8)
Does not the picture display when RCA cable plugged into component?
MAIN UNIT:
Is Component Y/Pb/Pr signal sent to pin
(2)/Y, (4)/Pb, (6)/Pr of CN6101?
Is Component Y/Pb/Pr signal sent to pin
(AC15)/Y0p, (AD16)/Pb0p, (AE16)/Pr0p
of IC U107?
YES
Check the setting of an external input
device that connects of CN6101
NO
NO
Check the circuits between IC U107 and
CN6101
Refer to “The picture doesn't appear in
all modes.”
YES

Vizio E60-C3 Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Full-Array
Supported video modes	1080p
Contrast ratio (dynamic)	5000000:1
Viewing angle, horizontal	176 °
Display refresh rates supported	120 Hz
Motion interpolation technology	-
Music apps	Pandora, Spotify
Video apps	Netflix, YouTube
Lifestyle apps	Facebook, Twitter
Audio decoders	DTS Studio Sound
RMS rated power	10 W
Number of speakers	2
PC in (D-Sub)	No
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Wi-Fi standards	Wi-Fi 4 (802.11n)
On Screen Display (OSD) languages	ENG, ESP, FRE
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Package depth	172 mm
Package width	1447 mm
Package height	902 mm
Package weight	25400 g
Sustainability certificates	ENERGY STAR
Certification	UL, cUL, FCC Class B, BET7/ICES-003 Class B, IC, HDMI (CEC, ARC), Dolby Digital

Weight and Dimensions

Stand width	1186 mm
Depth (with stand)	279.9 mm
Height (with stand)	851.4 mm
Weight (with stand)	21000 g
Depth (without stand)	64.26 mm
Width (without stand)	1353 mm
Height (without stand)	786.4 mm
Weight (without stand)	20600 g
