Installing the TV on a Wall
To mount your TV on a wall, you will need a wall mount. Consult
WKH LQIRUPDWLRQEHORZWRȴQGWKHDSSURSULDWHPRXQWIRU\RXU 79
model:
Installing a TV on a wall requires lifting. To prevent
injury or damage to the TV, ask someone to help you.
Do not use the screws that come installed in the back
of the TV to attach the TV to a wall mount. They are too
short to support the TV and are intended only to secure
the back panel and to improve sound quality.
WALL MOUNT SCREW LOCATIONS
E60-C3
Screw Size: M6 (not included)
Hole Pattern: ɋPP9[ɋPP+
Weight w/o Stand: 45.42 lbs
Be sure the mount you choose is capable of supporting the weight
of the TV. After you have determined that you have the correct
mount for your TV, you can begin the installation.
To install your TV on a wall:
1. Read the instructions that came with your wall mount and
make sure that you have four (4) screws of the correct length
for the combination of wall mount and TV.
2. Disconnect any cables connected to your TV.
3. 3ODFHWKH79IDFHGRZQRQDFOHDQȵDWVWDEOHVXUIDFH%HVXUH
the surface is clear of debris that can scratch or damage the
TV.
4. Remove the stands by loosening and removing the screws.
5. Remove the screws from the wall mount holes on the back of
the TV. Save these screws with the stands.
Note: If you remove the TV from the wall mount and set it up on
the stands, you must reinstall these screws.
6. Attach your TV and wall mount to the wall, carefully following
the instructions that came with your mount.
Use only with a UL-listed wall mount bracket rated for the
weight/load of this TV.
