$GMXVWLQJWKH&RORU&DOLEUDWLRQ6HWWLQJV
Color Calibration Settings allow you to make precise adjustments to
the picture and to create picture modes to save groups of picture
settings.
The Color Tuner, 11 Point White Balance, and test
patterns allow technicians to manually calibrate the TV.
Calibration requires specialized training, an input with
precisely set colors, and a specialized light meter.
To adjust the color calibration picture settings:
1. From the PICTURE menu, use
the Arrow buttons to highlight
&RORU&DOLEUDWLRQ and press
the OK button. The COLOR
CALIBRATION menu is displayed.
2. Use the Arrow buttons to
highlight the setting you wish to
adjust, then press the OK button
to change the setting:
• 3LFWXUH0RGH - Not directly
selectable (reference only).
Changes to Hue, Saturation,
and Brightness are saved
here and indicated with an
asterisk (*).
• Color Temperature - Not directly selectable (reference
RQO\&KDQJHVWR2VHWDQG*DLQDUHVDYHGKHUHDQG
indicated with an asterisk (*).
• Color Tuner$GMXVWWKH+6%FRORU5*%RVHWVDQG
11-point white balance, and display calibration test
patterns.
COLOR CALIBRATION
Picture Mode*
Color Temperature*
Color Tuner
Reset Color Tuner
• 5HVHW&RORU7XQHU - Resets the color tuner settings for the
current color temperature mode.
• If the current picture mode is a pre-set, the color
temperature is reset for all pre-set picture modes using
WKHFXUUHQWFRORUWHPSHUDWXUHPRGHΖWGRHVQRWDHFW
saved custom picture modes.
• If the current picture mode is a saved custom picture
mode, the color temperature only reset for that custom
SLFWXUHPRGHVΖWGRHVQRWDHFWSUHVHWSLFWXUHPRGHV
or other custom picture modes.
For example, suppose that:
• You have created two custom picture modes: “My Picture
Settings” and “Oliver.” They both use the Normal color
temperature, but you have adjusted it for each of the
modes.
—and—
• You have changed the Color Tuner settings for the
Normal color temperature while in the Calibrated picture
mode.
6R\RXKDYHȊ0\3LFWXUH6HWWLQJVȋZLWKDPRGLȴHG1RUPDO
FRORUWHPSHUDWXUHȊ2OLYHUȋZLWKGLHUHQWFKDQJHVWRWKH
Normal color temperature, and a third set of changes to the
Normal color temperature that applies to all of the pre-set
picture modes.
The Calibrated and Calibrated Dark picture modes both use
the Normal color temperature. If Calibrated is the current
picture mode when the Normal color temperature is reset,
WKHFKDQJHDHFWVERWKRIWKHVHSLFWXUHPRGHVEXWGRHV
not undo the changes to the color temperature for the “My
Picture Settings” or “Oliver” custom picture modes.
If “My Picture Settings" is the current picture mode when
the Normal color temperature is reset, the change only
DHFWVWKHȊ0\3LFWXUH6HWWLQJVȋSLFWXUHPRGH7KHFRORU
temperature changes to the “Oliver,” Calibrated, and
Calibrated Dark picture modes stay as they are.
