Vizio M551d-A2R User Manual

3
12
HDMI CABLE
HDMI is the intelligent, all-digital interface
that delivers both dazzling quality and
unmatched ease of use. HDMI technology
transmits crystal-clear digital video along with
multi-channel surround audio. HDMI-connected
devices have the ability to automatically adjust
themselves for optimal viewing.
COMPONENT CABLE
Component cables are designed to carry high
definition video signals along with additional
audio connections. Colors are delivered with
color information split up three different ways
over three connectors for video (separated into
Red, Blue and Green signals) and the left and
right audio connectors (Red and White).
AV CABLE
AV cables (or Composite cables) are the
traditional way of connecting your devices to
your TV. Video signals are sent over the yellow
connector while audio is sent over the red and
white connectors.
GOOD BETTER
HDMI
COMPONENT VIDEO
COMPONENT VIDEO
Y L R
R L Pr/Cr Pb/Cb Y HDMI
• HD Video Resolutions up
to 1080P
• HD Audio
• Digital Connection
• Audio and Video Signals
• HD Video Resolutions up
to 1080i
• Analog Connection
• Audio and Video Signals
• Video Resolutions up to 480i
• Analog Connection
• Audio and Video Signals
BEST
CONNECTING A DEVICE - AUDIO AND VIDEO CABLE TYPES

Vizio M551d-A2R Specifications

General

Display diagonal	55 \
LED backlighting type	-
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
3D	Yes
3D glasses quantity	8
RMS rated power	15 W
Number of speakers	2
PC in (D-Sub)	No
HDMI ports quantity	4
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	1
Product color	Black
Panel mounting interface	400 x 400 mm
Power consumption (standby)	1 W
Power consumption (typical)	91 W
Sustainability certificates	ENERGY STAR
Package depth	137.9 mm
Package width	1407 mm
Package height	915.9 mm
Package weight	27500 g

Weight and Dimensions

Depth (with stand)	257.05 mm
Height (with stand)	776.2 mm
Weight (with stand)	22730 g
Depth (without stand)	44.45 mm
Width (without stand)	1253 mm
Height (without stand)	723.9 mm
Weight (without stand)	20210 g
