Specifications
M501d-A2 M551d-A2 M651d-A2
Screen Size: 50” Class 55” Class 65” Class
Viewable Area: 49.50” 54.64” 65.00”
Dimensions w/ Stand:
w/o Stand:
44.13” x 27.79” x 8.54”
44.13” x 25.89” x 1.75”
48.61” x 30.56” x 10.12”
48.61” x 28.50” x 1.75”
57.45” x 35.45” x 10.12”
57.45” x 33.34” x 2.13”
Weight w/ Stand:
w/o Stand:
43.40 lbs
39.18 lbs
50.11 lbs
44.56 lbs
80.24 lbs
74.68 lbs
TV Type: LED LED LED
Refresh Rate: 240 Hz 240 Hz 240 Hz
Maximum Resolution: 1080P 1080P 1080P
Pixel Pitch: 0.570 mm (H) x 0.570 mm (V) 0.630 mm (H) x 0.630 mm (V) 0.744 mm (H) x 0.744 mm (V)
Dynamic Contrast Ratio: 10,000,000:1 10,000,000:1 10,000,000:1
Response Time: 5 ms 5 ms 8 ms
Brightness: 350 nits 350 nits 350 nits
Viewing Angle: 178° (H) / 178° (V) 178° (H) / 178° (V) 178° (H) / 178° (V)
HDMI Inputs: 4 4 4
Component Video Inputs: 1 1 1
Composite Inputs: 1 (Shared with Component) 1 (Shared with Component) 1 (Shared with Component)
RF Antenna Input: 1 1 1
USB 2.0 Ports: 2 2 2
Ethernet: 1 1 1

Vizio M551d-A2R Specifications

General

Display diagonal	55 \
LED backlighting type	-
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
3D	Yes
3D glasses quantity	8
RMS rated power	15 W
Number of speakers	2
PC in (D-Sub)	No
HDMI ports quantity	4
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	1
Product color	Black
Panel mounting interface	400 x 400 mm
Power consumption (standby)	1 W
Power consumption (typical)	91 W
Sustainability certificates	ENERGY STAR
Package depth	137.9 mm
Package width	1407 mm
Package height	915.9 mm
Package weight	27500 g

Weight and Dimensions

Depth (with stand)	257.05 mm
Height (with stand)	776.2 mm
Weight (with stand)	22730 g
Depth (without stand)	44.45 mm
Width (without stand)	1253 mm
Height (without stand)	723.9 mm
Weight (without stand)	20210 g
