WALLMOUNTING THE TV

First you will need a wall mount. Consult the provided table below to find the

appropriate mount for your TV.

Be sure the mount you choose is capable of supporting the weight of the TV.

To install your TV on a wall:

1. Disconnect any cables connected to your TV.

2. Place the TV face-down on a clean, flat, stable surface. Be sure the surface is

clear of debris that can scratch or damage the TV.

3. If attached, remove the stands by loosening and removing the screws.

4. Attach your TV and wall mount to the wall by carefully following the instructions

that came with your mount. Use only with a UL-listed wall mount bracket rated

for the weight/load of your TV.

TIP: Installing a TV on a wall requires lifting. To prevent injury or

damage to the TV, ask someone to help you.

WARNING: Do not use the screws that are included inside the wall

mount holes to mount TV.

Note: The image shown here is for illustrative purposes only and may be subject to change. The actual number

of ports and their locations may vary, depending on the model.

P65Q9-H1 P65Q9-H61 P75Q9-H1 P75Q9-H61

Screw Size: M6 M6 M8 M8

Hole Depth: 14 mm 14 mm 14 mm 14 mm

Hole Pattern: 400 mm x 400 mm 400 mm x 400 mm 400 mm x 400 mm 400 mm x 400 mm

Weight w/o Stand: 54.28 lb (24.62 kg) 54.28 lb (24.62 kg) 74.37 lb (33.73 kg) 74.37 lb (33.73 kg)
