MOUNTING LOCATION
Reader RD-4F
EXIT 300M button
The Reader is mounted on a wall near the entrance door,
or on a fixed door leaf, outside the entrance doorway.
The button is mounted on a wall near the entrance
door, inside the entrance doorway.
may
s
Note. Any button with NO contacts be used
as well. See the example of connection diagram
EXIT 300M
EXAMPLES OF WIRING DIAGRAMS
button is intended for use with an
electromagnetic lock to ensure lock release from
inside of the building.
in the section .
47 mm
75 mm
1100 100 mm±
47 mm
75 mm
1100 100 mm±
75 mm
Control Unit KTM600M
The Control Unit is located in any convenient place indoors.
Do not mount the unit near heating equipment.WARNING.
135 mm
