5) The three values for the max. cable cross-section are for single core, flexible wire and flexible wire with sleeve, respectively.
PK37 PK55 PK75 P1K1 P1K5 P2K2 P3K0 P4K0 P5K5 P7K5
Typical Shaft Output (hp [kW])
0.5
[0.37]
0.75
[0.55]
1
[0.75]
1.5 [1.1] 2 [1.5] 3 [2.2] 4 [3] 5 [4] 7.5 [5.5] 10 [7.5]
Enclosure IP20/IP21 A2 A2 A2 A2 A2 A2 A2 A2 A3 A3
Enclosure IP20 (FC 301 only) A1 A1 A1 A1 A1
Enclosure IP55, IP66 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A5 A5
Output current
High overload 160% for 1 min.
Shaft output [hp, kW]
0.5
[0.37]
0.75
[0.55]
1
[0.75] 1.5 [1.1] 2 [1.5] 3 [2.2] 4 [3] 5 [4] 7.5 [5.5] 10 [7.5]
Continuous (3x380–440 V) [A] 1.3 1.8 2.4 3 4.1 5.6 7.2 10 13 16
Intermittent (3x380–440 V) [A] 2.1 2.9 3.8 4.8 6.6 9.0 11.5 16 20.8 25.6
Continuous (3x441–500 V) [A] 1.2 1.6 2.1 2.7 3.4 4.8 6.3 8.2 11 14.5
Intermittent (3x441–500 V) [A] 1.9 2.6 3.4 4.3 5.4 7.7 10.1 13.1 17.6 23.2
Continuous kVA (400 V AC) [kVA] 0.9 1.3 1.7 2.1 2.8 3.9 5.0 6.9 9.0 11.0
Continuous kVA (460 V AC) [kVA] 0.9 1.3 1.7 2.4 2.7 3.8 5.0 6.5 8.8 11.6
Max. input current
Continuous (3x380–440 V) [A] 1.2 1.6 2.2 2.7 3.7 5.0 6.5 9.0 11.7 14.4
Intermittent (3x380–440 V) [A] 1.9 2.6 3.5 4.3 5.9 8.0 10.4 14.4 18.7 23.0
Continuous (3x441–500 V) [A] 1.0 1.4 1.9 2.7 3.1 4.3 5.7 7.4 9.9 13.0
Intermittent (3x441–500 V) [A] 1.6 2.2 3.0 4.3 5.0 6.9 9.1 11.8 15.8 20.8
Additional specifications
IP20, IP21 max. cable-cross section
5)
(line power, motor, brake and load
sharing) [mm
2
(AWG)]
2)
4,4,4 (12,12,12)
(min. 0.2(24))
IP55, IP66 max. cable cross-section
5)
(line power, motor, brake and load
sharing) [mm
2
(AWG)]
4,4,4 (12,12,12)
Max. cable cross-section
5)
with
disconnect
6,4,4 (10,12,12)
Estimated power loss
at rated max. load [W]
4)
35 42 46 58 62 88 116 124 187 255
Weight, enclosure IP20 (lb [kg]) 10.36
[4.7]
10.36
[4.7]
10.58
[4.8]
10.58
[4.8]
10.8
[4.9]
10.8
[4.9]
10.8 [4.9]
10.8
[4.9]
14.55
[6.6]
14.55
[6.6]
Enclosure IP55, IP66 13.5 13.5 13.5 13.5 13.5 13.5 13.5 13.5 14.2 14.2
Efficiency
4)
0.93 0.95 0.96 0.96 0.97 0.97 0.97 0.97 0.97 0.97
0.5–10 hp [0.37–7.5 kW] only available as 160% high overload.
Table 10.4 Line Power Supply 3x380–500 V AC (FC 302), 3x380–480 V AC (FC 301)
