22
Red
Purple
Green
From PREDATAIR60
activation circuit
Throttle control
12V input when activation circuit is switched on
and the purple wire is grounded by the control system
Speed 1 Speed 2
Set Speed 1 to the miniumum GPM rating
Set Speed 2 to achieve the desired CFM
Figure 16 – Two speed operation
