Vogelsang VX186QD - Fig. 30: Cartridge Mechanical Seal Change on the QD Cover

Repair
68
WBV.PU.002.EN VX186QD V2.0
1
Hexagon head bolt
2
Wear plate
3
Retaining ring
4
O-ring
5
Seal carrier
6
O-ring
7
Set screw
8
Cylinder head bolt
9
Hexagon head bolt
10
Hexagon nut*
11
Cartridge mechanical seal
12
O-ring
13
Washer*
14
Hexagon head bolt*
A
Tool WKZ0457 (includes pos. 8, 9)*
B
Tool WKZ0119*
C
Tool WKZ0098*
* included in tool with part no. PBA0009
Fig. 30: Cartridge mechanical seal change on the QD cover
