CINEMA HORIzONTAL fASTENING
Before installing the polarizator window in front of the projector lens, make sure you have all the needed tools and the instruction manual. This
wall xing part is provided with all the screws and wall anchors you might need.
Follow the instructions to fasten this kit.
1
2
3
4
5
7.2
8
9 10
6
Parts Quantity Description
1 x 1 Polarizer xation
2 x 7 Metallic bar
3 x 4 Fixation bar
4 x 10 Screws for product xation
5 x 2 Mounting plate
6 x 2 Screws for mounting plate
Parts Quantity Description
7.1 x 1 Key (small size)
7.2 x 1 Key
8 x 6 Assembly part
9 x 1 Security system
10 x 4 Cover
STEP 1
7.1
To Next Page
