Engine codes CJDA, CJDD
– Connect coolant hose -arrow- to oil cooler.
Engine codes CPYA, CPYB, CPYC, CPYD, CPYE
Connect coolant hose -arrow- to oil filter bracket.
Continuation for all engine codes
With cooling system charge unit -VAS 6096-
– Screw adapter -V.A.G 1274/8- onto expansion tank.
– Fill coolant circuit using cooling system charge unit
-VAS 6096-, refer to ⇒  Operating manual for cooling system
charge unit -VAS 6096-.
Without cooling system charge unit -VAS 6096-
– Fill with coolant slowly up to max. mark on expansion tank.
With and without cooling system charge unit -VAS 6096-
– Fit expansion tank cap.
– Start engine and maintain an engine speed of about 2,000
rpm for about 3 minutes.
– Run engine until radiator fan cuts in.
WARNING
Hot steam may escape when expansion tank is opened.
Place cloth over cap and open with caution.
– Check coolant level and top-up if necessary. When the en-
gine is at normal operating temperature, the coolant level
must be at the max. mark; when the engine is cold, between
the min. and max. marks.
1.6 Renewing coolant pump, engine codes
CJDA, CJDD, CPYA, CPYB, CPYC,
CPYD, CPYE
Renewing coolant pump, engine codes CPYA, CPYB, CPYC,
CPYD, CPYE, CJDA, CJDD ⇒ Page 288.
Industriemotoren - Industrial Engines 2009 ▶
Workshop Manual for Diesel Engine (2.0 l/36-75 kW_EA 189) 05.2015
3
1 Removing and installing parts of cooling system
287
